Made to Order and dispatched within 10-15 business days.
Aston Martin DBX Wheel Spacer Kit
Give your Aston Martin DBX a wider, more confident stance with Brightstone Engineering’s precision-machined hubcentric wheel spacers. Designed specifically for the DBX’s 5×128 bolt pattern and 75.1 mm centre bore, these spacers deliver OEM-grade accuracy, improved stability, and a transformed road presence.
Machined in the UK from aerospace-grade 6082-T6 billet aluminium, each spacer is finished with a premium black anodised coating for exceptional corrosion resistance and long-term durability.
Key Features
- True hubcentric design for perfect wheel alignment and zero vibration
- CNC-machined from 6082-T6 aerospace aluminium
- Black anodised finish for strength, corrosion resistance, and a premium appearance
- Supplied with extended high-tensile lug bolts (M14×1.5) matched to Aston Martin specifications
- Wider track = improved cornering & stability
- Provides additional clearance for upgraded brakes and wider wheels
- Fully designed, machined, finished and inspected in the UK
The Aston Martin DBX Brightstone Engineering Spacer Kit Includes
- 2× Aston Martin DBX wheel spacers (select thickness above)
- Stud Adapter Kit / Open Ended Wheel Nuts / extended bolts - Model Dependent
- Installation guide with torque settings
Compatibility: Aston Martin DBX
These spacers are engineered for all Aston Martin DBX models using the standard 5×128 hub.
Aston Martin DBX AM8 (2020–2024)
- Petrol 3.0L Turbo I6 (M256)
- 429 hp / 320 kW
- All markets including China
- Production years: 2021–2024
Key vehicle specifications:
- Centre Bore: 75.1 mm
- Bolt Pattern: 5×128
- Wheel Fasteners: Lug bolts
- Thread Size: M14 × 1.5
- Torque: 175 Nm
If your DBX uses the factory wheel and hub setup, these spacers will fit precisely.
Installation Notes
- Professional installation recommended
- Torque lug bolts to 175 Nm (Aston Martin DBX specification)
- Minimum 8 full turns of thread engagement required
- Suitable for OEM and most aftermarket wheel designs
Shipping & Warranty
- Fast UK dispatch
- Worldwide shipping available
- Lifetime warranty against manufacturing defects
